APEX COR Intelligent Return Pump – Neptune Systems

Description

The intelligent Neptune COR Return Pumps areeasily the smartest pumps available. Directly connecting to any Apex controller through an Aquabus Port, but if you do not have a controller, don’t worry, you don’t need one! COR pumps come standard with advanced control features that can be found by using the Apex Fusion Cloud Software(Apex required). Add a COR pump to your system today to see the difference.

• IQ-Level Technology
• Energy Efficient
• Extremely Quiet
• AquaBus Communication Connection
• Temperature Monitoring
• Internal or External

The COR can be connected to an Apex, but it can also be used in a standalone method, where the controller lets you have simple control over the pump, like increasing and decreasing the speed as desired. Connecting the COR to an Apex Controller can unlock much more potential.

The COR pumps were built from the ground up with control in mind. Have power over everything including the CORs output percentage, real-timeoperational feedback, compared feed routines, pump status can all be monitored and controlled with Apex Fusion. Once the COR pump is plugged into a 1Link port, and after acouple button presses you can set the pumps flow rate and feed mode settings. By enabling IQ-Level, you can set the min and max flow rates for your aquarium.

The powerful COR-20 can push up to 2000 gallons per hour with an incredibly efficienthead-loss curve. The COR-15 puts out great flow (1500 GPH) while at the same time being super-stingy on power.Each pump comes with multiple different outputfittings that let you adapt the COR pumps output to match your reef tanks current plumbing size. It is suggested to use the largest 1.25″ Union that is included, but it is totally fine to use the other 0.75″ or 1.0″ adapters if needed.

Because not all aquariums are alike, Neptune Systems included IQ-Level technology with every COR pump. Customize the minimum and maximum speed settings for your tanks plumbing to the ideal flow rate, but also the minimum flow rate for in tank flow and feed modes as well.

Know what is going on with your pump at all times. COR pumps come loaded with features that let you monitor your aquariums “heart” giving you the chance to fix something before it fails. Saltwater aquariums are notoriousfor creating calcium and other mineral build up on pumps and there internal parts that can inhibit the flow but more importantly could cause damage to the pump. Neptune Fusion lets you monitor the pumps internal temperature along with its wattage draw and flow rate allowing you to set alarms and alerts if something goes out of their normal thresholds. If the temperature of the pump increases to unsafe levels, the COR will actually slow itself down until temperatures reach a safe level again, giving you time to react and maintain the pump.

Specifications

COR-20

Pump Dimensions – 3.875″ W x 4.875″ H x 6.250″ D

Driver Dimensions – 3″ W x 4″ H x 1″ D

Max Flow – 2000 GPH

Max Head – 20FT

Power Consumption – Less than 90W @ 120VAC

COR-15

Pump Dimensions – 3.875″ W x 4.875″ H x 6.250″ D

Driver Dimensions – 3″ W x 4″ H x 1″ D

Max Flow – 1500 GPH

Max Head – 14FT

Power Consumption – Less than 60W @ 120VAC

Package Includes:

1x COR Pump Body

1x COR Driver Controller

1x 100W DC Power Supply

1x 1.25″ PVC Union (slip to BSPP)

1x 1″ Slip Fitting

1x 0.75″ Slip Fitting

1x 3-foot AquaBus Cable
